Switchgear

ABB Switchgear products include options for low voltage and medium voltage switchgear. Comprised of electrical disconnect switches, fuses or circuit breakers used to control, protect, and isolate electrical equipment.

ABB ReliaGear LV SG low voltage switchgear

Low Voltage Switchgear

This new generation Low Voltage switchgear platform provides the latest technological innovations and reliability that customers expect from ABB.
The MNS® metal-enclosed LV power circuit breaker switchgear for ANSI/NEMA/UL offers excellent flexibility due to the modularity of both the electrical & mechanical design…
Leverages state-of-the-art technology to protect low voltage power distribution systems, representing a significant advantage over traditional switchgear.
Continues the AKD tradition while delivering enhanced arc flash protection. It fits into a smaller area for the most common configurations. Replaces the AKD-10 switchgear.
Low voltage switchgear for use with Gerapid High-Speed DC circuit breakers.

Medium Voltage Switchgear

ABB's medium-voltage switchgear portfolio helps protect and control electrical equipment in commercial, industrial and utility applications worldwide.

Advance® is ABB’s ANSI platform for 5, 15 and 27 kV rated metal-clad, medium voltage switchgear.
SafeGear®  medium voltage, metal-clad switchgear for primary distribution up to 15 kV suitable for indoor installations.
Narrow design medium voltage switchgear for primary distribution up to 15 kV suitable for indoor applications
Digitalization simplifies construction while increasing safety and versatility
Well-proven ZX switchgear for applications up to 40.5 kV, 3150 A, 40 kA
SafePlus is a metal-enclosed compact switchgear system for distribution applications from 6 to 40.5 kV
Medium voltage (MV) SF6-insulated ring main unit for IEC secondary distribution applications up to 40.5 kV, 630A
Medium voltage gas-insulated compact switchgear for secondary distribution, 24 kV, 630A

Abbreviated Switchgear & Components

Fixed parts for fitting circuit breakers/contactors and pre-assembled modules for constructing medium voltage switchgear up to 40.5 kV, 2500 A, 25 kA.
The ABB Emax Link 2 UR 1558 structures provide a turnkey solution for OEMs and are designed and tested to UL 1558 standards.
MV switchgear components for OEM panel builders, up to 15 kV, 3000 A, 63 kA, and 27 kV, 2000 A, 25 kA
Medium voltage preassembled units to be used as components for primary distribution air-insulated switchgear.

Load Interrupter Switchgear

Provides dependable, economical load switching and protection for MV circuit applications from 2.4 through 15kV in 600 or 1200 ampere load interrupting ratings.
ABB’s Breakmaster V solution provides reduced Arc Flash incident energy levels for customers on their existing MV equipment.
GE's Medium Voltage LIS Retrofit solution provides reduced Arc Flash incident energy levels for customers on their existing MV equipment.

Previous Generation Switchgear

This section is for documentation related to AKD-10.
This section is for documentation related to earlier generations of Entellisys.
